World Headquarters
Multi-Tech Systems, Inc.
2205 Woodale Drive
Mounds View, MN 55112 U.S.A.
Tel: (612) 785-3500 or (800) 328-9717
Fax: (612) 785-9874
BBS: (612) 785-3702 or (800) 392-2432
Tech Support: (800) 972-2439
Fax Back: (612) 717-5888
Web Site: http://www.multitech.com
FTP Site: ftp://ftp.multitech.com
U.K. Sales Office
Multi-Tech Computers, Ltd.
Unit 1, Thames Court
2 Richfield Avenue
Reading, Berkshire RG1 8EQ U.K.
Tel: +(44) 1189-597774
Fax: +(44) 1189-597775
BBS: +(44) 1189-595564
Multi-Tech Systems, Inc., has sales offices in China, France, Germany, India, Mexico, the Netherlands, and
the United Kingdom. For more information, contact Multi-Tech world headquarters.
Copyright © 1997 by Multi-Tech Systems, Inc. All rights reserved.
10/97 86000313 FB doc # 1312
MultiModemManager
™
Starter
Specifications
AN508TP Networking Hub
Dimensions:
19" W × 1.75" H × 11.5" L
48.3 cm × 4.4 cm × 29.2 cm
Weight: 8.0 lbs. (36 kg)
LEDs:
TRF (Traffic), JAM, COL (Colli-
sion), PWR (Power), LI (Link
Integrity), AUI CRS, CS (Coax)
CRS, UTP Link Integrity, and 16
Carrier Sense LEDs
Connectors:
RJ45 internal crossover for twisted
pair connections
DB15S for AUI connection
BNC for coax connection
Ports:
8 twisted pair
1 AUI
1 coaxial
Power Rating:
115/230v AC (Auto-select),
47-63 Hz
Power Consumption: 30 watts
Data Transfer Rate: 10M bps
Topology: Star
Protocol: CSMA/CD
Compatibility:
10BaseT, 10Base5, and 10Base2
Multi-Tech EN-Series NICs
Operating Temperature:
32° to 158° F (0° to 70° C)
Humidity Range:
5-95% (non-condensing)
Warranty: Two years
AN516TP Networking Hub
Same as the AN508TP, except for the
following:
Ports:
16 twisted pair
1 AUI
1 coaxial
PS4800A Power Supply
Dimensions:
4.0" W × 4.7" H × 15.7" L or
(9.2 cm × 9.9 cm × 11.5 cm)
Weight: 4.0 lbs. (1.8 kg)
Power: 115v AC
Load Compensation:
Output voltage regulation stable to
full load (96 modems)
Input:
90 to 260v AC RMS @ 47 to 63 Hz
Current: 1.5A @ 220v full load
Insulation:
3750v RMS dielectric strength
Required chassis:
CC4800A with 115v receptacle
(any connector configuration)
PS4800A/-48v Power Supply
Same as the PS4800A, except for the
following:
Power: -48v DC
Input: -48v battery or power supply
Required chassis:
CC4800A with -48v DC connec-
tors
PS4800 Power Supply
Same as the PS4800A, except for the
following:
Required Chassis: CC4800
Load Compensation: None
PS4800/-48v Power Supply
Requires a special version of the CC4800
card cage not listed.
Power: -48v DC
Each model carries a two-year
warranty and is manufactured in
Mounds View, MN, U.S.A.
Trademarks: MultiModemManager, Multi-Tech, and the
Multi-Tech logo: Multi-Tech Systems, Inc. / Amphenol:
Amphenol Corporation / Windows: Microsoft
Corporation.
