CommPlete 4000 Communications Server

Quick Start Guide

9

Installing Your CommPlete 4000

Serial Card Upgrades

As shown in Figure 5c, installation of expansion cards is simpler in the outer slots than in the inner

expansion slot.

}

Shipped Configuration

120

120

Preferred

expansion

slots

120

Installing expansion card here

requires removal of card cage.

Figure 5c. Convenience of using outer expansion slots before the inner slot
